New and Used Metalworking Machinery


.156" x 12" LITTELL 3 Over 4 Straightener, Entry Pinch, Control Arm, 3 HP   Our stock number: 52268

.156 x 12 LITTELL 3 Over 4 Straightener, Entry Pinch, Control Arm, 3 HP

Click on picture below for larger version
.156 x 12 LITTELL 3 Over 4 Straightener, Entry Pinch, Control Arm, 3 HP.156 x 12 LITTELL 3 Over 4 Straightener, Entry Pinch, Control Arm, 3 HP.156 x 12 LITTELL 3 Over 4 Straightener, Entry Pinch, Control Arm, 3 HP.156 x 12 LITTELL 3 Over 4 Straightener, Entry Pinch, Control Arm, 3 HP
.156 x 12 LITTELL 3 Over 4 Straightener, Entry Pinch, Control Arm, 3 HP.156 x 12 LITTELL 3 Over 4 Straightener, Entry Pinch, Control Arm, 3 HP.156 x 12 LITTELL 3 Over 4 Straightener, Entry Pinch, Control Arm, 3 HP

AGE: 1982
MODEL NUMBER: 412-7 PDL

SPECIFICATIONS:

3 Over 4
All Rolls Driven

Capacity: .156" Thick x 12" Wide

Straightener Rolls: 3" Dia. x 12-1/2" Long
Pinch Roll Diameter: 4.25"
Center-to-Center: 5-1/2"

Speed, Max., Approx.: 37 FPM

Feeding Line Height: 48"
Direction: Right to Left

EQUIPPED WITH:

Entry Pinch
Control Arm, Hi/Lo/Off
Allen-Bradley Reversing Starter and Controls

MOTOR DATA: 3 HP, 230/460/60/3

OVERALL DIMENSIONS: 60" x 48" x 60" High
WEIGHT: 4,000 Lbs.
