New and Used Metalworking Machinery


135 Ton GROTNES Hyd Expander, 12" Cyl Dia, 8" Cyl Str, (12) Adj Jaws, 15 HP   Our stock number: 50956

135 Ton GROTNES Hyd Expander, 12 Cyl Dia, 8 Cyl Str, (12) Adj Jaws, 15 HP

AGE: N/A

SPECIFICATIONS:

Expansion Capacity, Max.: 135 Tons
Number of Radial Jaws: 12
Hydraulic Cylinder Diameter: 12"
Vertical Stroke of Cylinder: 8"
Radial Expansion of Jaws: 1/2"
Draw Bar Diameter: 1-1/2"
Collapsed Diameter: 4-3/4"
Expanded Diameter: 5-1/4"
Distance Floor to Horizontal Jaws: 63"
O.D. of Vertical Jaws (Column): 5.5"
O.D. of Horizontal Jaws: 36"
Height of Vertical Jaws: 18-1/2"
Expansion Rate Speed: 50 IPM
Contraction Rate Speed: 50 IPM
Hydraulic System Operating Pressure: 2500 PSI
Hydraulic Pump: OilGear DPG122506

EQUIPPED WITH: (12) Adjustable Jaws
(12) Brass Vertical Jaws
Operators Pendant Control w/Auto-Cycle
Dual Palm Actuation
Jog Expand
Jog Release
Cycle Timer
360 Deg. Operator Platform
360 Deg. Operator Platform

Motor Data: 15 HP, 230/460/3/60

Overall Dimensions, Expander: 54" W x 54" L x 8'4" High
Overall Dimensions, Hydraulic Unit: 32" W x 66" L x 46" High
Overall Dimensions, Control Unit: 20" W x 17" L x 43-1/2" High
Weight: 10,000 Lbs. Approx.
