SPECIFICATIONS (As Built, Can Be Built to Specifications):
Each hopper is equipped with it's own DC motor. Then the
hopper is plugged into the receiving machine which could be
used to control the rate of the unloading. Or a DC
controller can be purchased to set the speed of the
unloading to time it with the rate of use of the material
stored in the hopper.
Stackable Up To (4) High
Can Hold 4,000 Parts Of 10mm Diameter
Part Length: 24" to 40"
Weight, Max.: 4,500 Lbs.
AVAILABLE AT ADDITIONAL COST: DC Speed Control For
Loading / Unloading Station
NOTE: Machine Can Come With A 110 Volt Plug Or A Pigtail
To Connect To The Machine Being Fed
MOTOR DATA: 90 Volt DC
OVERALL DIMENSIONS: 48" W x 45" L x 33-3/8" High
WEIGHT: 650 Lbs.
CONDITION: New, Unused
At Location ........................... Toledo, OH
