SPECIFICATIONS:
Length: 10' to 24' (Or per Your Application)
Diameter, Rounds: 1/2" - 3-1/2" (or as Required)
Squares: 2" Max.
Hexagon: 2-1/2" Max.
Production Rate: 6 Sec. Cycle Time Typical, Material
Removal Dependent
Optional Two Parts/Cycle Available - Ask for Details
Part Transfer Via 1.) Push Type Chain Driven System OR 2.)Walk-
ing Beam
Quick Change Tool Inserts, Easily Accessible
Custom Design Inline or Offline, from Infeed to Bundling
Auxiliary Handling Systems Available at an Additional Charge
Cutter Heads Fed by Hydraulic Cylinder with Rapid & Slow Advance
Controlled by Linear Displacement
Diameter & Length Adjustments are all Controlled by the Operator
from a Touch Screen Interface thru PLC Control.
Head Centerline Adjustments are made by Motorized Jack Screws
with Linear Displacement Feed Back
Bar Length Adjustments are Motorized with Position Controlled by
Encoder
Encoder
Machining Head Positions Automatically Locked by Hydraulic
Cylinders
WARRANTY: Fully Warranted - Fabrication: 2 Years, Original
Engineering: 5 years, Purchased Components by
Vendor's Standard Warranty.
Engineered & Built Domestically
At Location.................................................
**PHOTO & PRINT AVAILABLE
