4" CRITERION #400-4-2R CNC Tube Bender, 4-Axis, DOB, DBB, POB, Double Stack   Our stock number: 47903

4 CRITERION #400-4-2R CNC Tube Bender, 4-Axis, DOB, DBB, POB, Double Stack

Click on picture below for larger version
4 CRITERION #400-4-2R CNC Tube Bender, 4-Axis, DOB, DBB, POB, Double Stack4 CRITERION #400-4-2R CNC Tube Bender, 4-Axis, DOB, DBB, POB, Double Stack4 CRITERION #400-4-2R CNC Tube Bender, 4-Axis, DOB, DBB, POB, Double Stack4 CRITERION #400-4-2R CNC Tube Bender, 4-Axis, DOB, DBB, POB, Double Stack
4 CRITERION #400-4-2R CNC Tube Bender, 4-Axis, DOB, DBB, POB, Double Stack4 CRITERION #400-4-2R CNC Tube Bender, 4-Axis, DOB, DBB, POB, Double Stack4 CRITERION #400-4-2R CNC Tube Bender, 4-Axis, DOB, DBB, POB, Double Stack4 CRITERION #400-4-2R CNC Tube Bender, 4-Axis, DOB, DBB, POB, Double Stack

AGE: 2002
MODEL NUMBER: 400-4-2R

SPECIFICATIONS:

Max. Capacity: 4" OD x 0.200" Wall, Mild Steel
Max. CLR: 14"
Max. R1-R2: 6"
Max. Tube Over Mandrel: 144"
Max. Degree of Bend: 195 Deg.
Pressure Die Slide Stroke: 24"
CNC Axis #1, DOB: +/- 0.1 Deg.
CNC Axis #2, POB: +/- 0.1 Deg.
CNC Axis #3, DBB: +/- 0.004"
CNC Axis #4: Pressure Die Assist
Right Hand Bend
Double Stack (2 Different Radii)

EQUIPPED WITH:
Parker Servos
Mandrel Extraction
Programmable Mandrel Position
DOB, DBB, POB
Electrical & Control Schematics

NOTE: Full Machine Support Still Available From Manufacturer

CURRENT REPLACEMENT COST PER MANUFACTURER IS $275,000

At Location ...........................
Photos Available
