AGE: 1994
SPECIFICATIONS:
Stroke: X: 500mm
Y: 500mm
Z: 300mm
A: Continuous Rotation
C: Continuous Rotation
Feeding X, Y & Z: 20,000mm/min.
A & C: 30 RPM
Laser Head U-D Copy Type: Non-Contact Type
Workpiece (Pipe) Material: Hardening Carbon Steel
OD: 20 - 50mm
Wall Thickness: 1 - 3.5mm
Length: 5,000 - 7,000mm
Cutting Length: 500 - 1,400mm
Pipe (Material) Shelf
Loading Pipe Size, OD: 20 - 50mm
Length: 5000 - 7000mm
No. of Pipe Stock: 200 Pipes
Stock Weight: 4,000 Kg
Pipe Feeder:
Type: V-Roller Type
Speed: 20 m/min
Drive: AC Motor
Positioning Stopper:
Travel Range: 1,400mm
Drive: AC Motor
Drive: AC Motor
High Frequency Discharge Excited High Speed CO2 Gas Laser:
Structure: Resonator, Power Integrated Type
Rated Output: 1500 W
Wave Length: 10.6um
Beam Mode: Low-Order Mode
Beam Polarization Degree: 45 Degrees Linear
Polarization
Beam Diameter at Exit: Approx. 24
Beam Divergent Angle: 2 mrad or less
Pals Output Order Frequency: 5 - 2000 Hz
Pals Output Order Due: 0 - 100%
Laser Gas: CO2: He: N2 - Mixed Gas
Consumption: Approx. 10 L/h
Cooling Water: 50 L/Min. or More
Electric Supply: AC 200V 50/60 Hz
AC 220V 60 Hz
Supplied Electricity: 23 kVA
Weight: 700 Kg Approx.
At Location................................................
**PHOTO AVAILABLE
