AGE: 1973
MODEL NUMBER: WRPH 230
SPECIFICATIONS:
Material Direction: Left To Right
Diameter, Peeled, Cold Drawn Or Ground Bar, Max.: 230.0mm
(9.055")
Diameter, Black Bar, Max.: 170.0mm (6.693")
Diameter, Min.: 30.0mm (1.181")
Angular Adjustment, Top & Bottom Rolls: 10 to 20 Degrees
Straightening Force, Hyd. Cushioned: 450.0 Metric Tons
495.0 Short Tons
Straightening Force, Fixed, No Cushion: 580.0 Metric Tons
638.0 Short Tons
Straightening (Throughput) Speed: 3.0 to 16.0 M/Min.
(9.8 to 52.5 F/Min.)
Straightening Roll RPM: 5.1 to 27.2
Roll Center Diameter Both Rolls: 700.0mm (27.559")
Roll Length Both Rolls: 1,200mm (47.244")
Re-Work Of Straightening Roll Diameter: 20.0mm (0.787")
Gap Between The Rolls, Max.: 300.0mm (11.811")
Range Of Guiding Gibs: 1st - 25.4mm to 41.2mm
1.0" to 1-5/8"
2nd - 41.2mm to 66.7mm
1-5/8" to 2-5/8"
3rd - 66.7mm to 111.1mm
2-5/8" to 4-3/8"
4th - 111.1mm to 177.8mm
4-3/8" to 7.0"
5th - 177.8mm to 230.0mm
7.0" to 9.0"
Main 3-Speed Drive Motors, Power/RPM Per Roll:
Top/Bottom Roll A: 396 RPM, 60.0 kW ( 80.0 HP)
Top/Bottom Roll B: 1,640 RPM, 250.0 kW (335.2 HP)
Top/Bottom Roll C: 2,100 RPM, 250.0 kW (335.2 HP)
EQUIPPED WITH:
8 to 10 Meter Long Entry Rack
Entry Canal
Entry Pinch Roll
Machine With Gear Reducers
Exit Pinch Roll
Exit Canal
8 to 10 Meter Long Collecting Pockets
MOTOR DATA: Hydraulic System - 55.0 kW (73.7 HP), 1,500 RPM
Height Adjust - 2.3 to 4.4 kW (3.1 to 5.9 HP),
750 to 1,500 RPM
Guide Plate Adjust - 4.0 kW (5.4 HP), 1,500 RPM
Angular Adjust - 1.5 kW (2.0 HP), 750 RPM
Entry / Exit - (2) 11.0 kW (14.7 HP), 1,500 RPM
Emulsion Pump #1 - 2.0 kW (2.7 HP), 3,000 RPM
Emulsion Pump #2 - 1.4 kW (1.9 HP), 3,000 RPM
WEIGHT: 205,740.0 kgs (453,574 Lbs.) With Tables
CONDITION: Gearboxes in Very Good Condition, But The Balance
Of The Machine Requires Rebuilding And The Electrics
and Electronics (Including The Main Motors) Must
Be Installed New
At Location ...........................
