40"X, 24"Y, 25"Z, TREE ZPS MODEL #1060 VERTICAL MACHINING CENTER, 1993,   Our stock number: 47290

40 X, 24 Y, 25 Z, TREE ZPS MODEL #1060 VERTICAL MACHINING CENTER, 1993,

Click on picture below for larger version
40 X, 24 Y, 25 Z, TREE ZPS MODEL #1060 VERTICAL MACHINING CENTER, 1993,40 X, 24 Y, 25 Z, TREE ZPS MODEL #1060 VERTICAL MACHINING CENTER, 1993,40 X, 24 Y, 25 Z, TREE ZPS MODEL #1060 VERTICAL MACHINING CENTER, 1993,

AGE: 1993

SPECIFICATIONS:

TRAVEL RANGE:
Saddle Travel, X-Axis: 40"
Table Travel, Y-Axis: 24"
Spindle Head Travel, Z-Axis: 25"
Feed Rates in X, Y, Z Axes: 315 IPM
Rapid Traverse in X, Y, Z Axes: 787 IPM
Distance of Spindle Nose to Table: 3.9" - 28.9"
Distance of Spindle Center Line to Column: 25"
Accuracy - Positioning: 0.001"
Accuracy - Repeatability: 0.0004"
WORK TABLE:
Working Area: 50" x 23.2"
Number of T-Slots x Width: 5 x 0.708"
Floor to Table Surface: 35.4"
Max. Load: 2000 Lbs.
SPINDLE:
Speed in Low Range: 0 - 2000 RPM
Speed in High Range: 2001 - 8000 RPM
Output: 15 HP
Output at Overloading (S6-30 min): 20 HP
TOOL CHANGER:
Tool Storage Capacity: 24 Tools
Tool Interchange Time: 8 Seconds
Max. Tool Diameter: 6.3"
Max. Tool Length: 11.8"
Max. Tool Weight: 17.6 Lbs.
Max. Weight of All Tools: 120 Lbs.
Max. Weight of All Tools: 120 Lbs.

EQUIPPED WITH: Lots of CAT 40 Tooling

Motor Data: Spindle Drive: Continuous - 15 HP, 1500 RPM
30 Min. - 20 HP, 1500 RPM
Coolant Pump: 1.5 HP, 3450 RPM

At Location..............................................
**PHOTO AVAILABLE
