AGE: 1986
SPECIFICATIONS:
Working Range: 8mm to 50mm Dia. Chip Forming
8mm to 90mm Dia. Chip Forming & Chipless
Cutter-Head Speeds, Infinitely Adjustable: 100 to 1000 RPM
Chamfering Speeds: 25 to 1200 RPM
Tool Feed: 0 to .03 mm/Rev.
Length Stop: 5mm to 500mm
Stock Clamping, Tool Feed, Work Piece Removal & Transfer
And The Clamping Devices And Feed Of The End Working
Facility Are Hydraulically Controlled By An
Electric/Electronic Program Circuit
Program Sequence Governed By A Stored Program Control "SPS"
EQUIPPED WITH:
An Error Diagnostic Display In The Control Panel Which
Indicates Any Faults And Allows Them To Be Pinpointed
Easily And Immediately
An Assortment Of Collets, Clamping Jaws And Cut-Off &
Chamfering Tools
MOTOR DATA: 5.0 kW Spindle
4.0 kW Hydraulic
2.5 kW Chamfer, (2) Each
0.5 kW Coolant Pump
0.5 kW Bar Feed
0.8 kW Loading Magazine
VOLTAGE: 460/60/3 - 34 Amps
CUT-OFF & CHAMFERING UNIT: 84" L x 75" W x 80" H, 5,300 Lbs.
LOADING MAGAINE: 18' L x 3' W x 4'6" H, 1,825 Lbs.
SWITCHGEAR CABINET: 48" L x 16' W x 75" H, 838 Lbs.
At Location ...........................
Photos Available
