12 STND CLINTON, Duplex, 1-1/4" Spdl Dia, 8" Horiz, 3-3/4" to 5" Vert, 7-1/2 HP   Our stock number: 32433

12 STND CLINTON, Duplex, 1-1/4 Spdl Dia, 8 Horiz, 3-3/4 to 5 Vert, 7-1/2 HP

Click on picture below for larger version
12 STND CLINTON, Duplex, 1-1/4 Spdl Dia, 8 Horiz, 3-3/4 to 5 Vert, 7-1/2 HP12 STND CLINTON, Duplex, 1-1/4 Spdl Dia, 8 Horiz, 3-3/4 to 5 Vert, 7-1/2 HP12 STND CLINTON, Duplex, 1-1/4 Spdl Dia, 8 Horiz, 3-3/4 to 5 Vert, 7-1/2 HP12 STND CLINTON, Duplex, 1-1/4 Spdl Dia, 8 Horiz, 3-3/4 to 5 Vert, 7-1/2 HP
12 STND CLINTON, Duplex, 1-1/4 Spdl Dia, 8 Horiz, 3-3/4 to 5 Vert, 7-1/2 HP12 STND CLINTON, Duplex, 1-1/4 Spdl Dia, 8 Horiz, 3-3/4 to 5 Vert, 7-1/2 HP12 STND CLINTON, Duplex, 1-1/4 Spdl Dia, 8 Horiz, 3-3/4 to 5 Vert, 7-1/2 HP12 STND CLINTON, Duplex, 1-1/4 Spdl Dia, 8 Horiz, 3-3/4 to 5 Vert, 7-1/2 HP

SPECIFICATIONS:

No. of Stands on Each Side: 12
Horizontal Distance Between Spindles: 8"
Vertical: 3-3/4" - 5"
Centerline of Lower Spindle to Base: 4-1/2"
Spindle Diameter: 1-1/4"
Shaft Extension: 4"
Pass Line Height: 38"
Line Speed: 375 FPM

EQUIPPED WITH:

Main Controls
Chain Driven
Entry Table
Current Tooling Both Sides (Ask for Photos)

Motor Data: 7-1/2 HP, 230/460/3/60 - 1745 RPM

Overall Dimensions: 12' L x 2'11" W x 3'7" High
Weight: 6,500 Lbs. Approx.
Condition: GOOD

Loaded on Truck...........Toledo, (Campbell St. Whse.) OH
**PHOTO AVAILABLE
