AGE: N/A
SPECIFICATIONS:
Max. Tube Capacity: 6"
Max. Solid Capacity: 3"
Length of Die: 18"
Width of Die: 8-1/2"
Thickness of Die: 6"
Passline Height: 49-1/2"
Dia. of Hole Thru Spindle: 6-1/2"
Hammer Blows Per Minute: 2400
EQUIPPED WITH: Hydraulic Unit w/(4) Motors
Main 2-Door Control Cabinet
ABBEY ETNA Hydraulic Feed Table
Motor Data: Hydraulic Unit: 30 HP, 230/460/3/60 - 1750 RPM
25 HP, 230/460/3/60 - 1755 RPM
25 HP, 230/460/3/60 - 1765 RPM
30 HP, 230/460/3/60 - 1770 RPM
Main: 100 HP Reliance, 440/3/60 - 715 RPM
NOTE: Complete Set of Spares Available. Including (But not
Limited to): (2) Spindles, Spindle Bearing Housing, Head
w/New Ring. All Parts are Available at an Additional
Negotiable Cost.
Overall Dimensions: Hyd. Unit: 8' L x 8" W x 6'2" High
Control Cab.: 5'1" L x 1'2" W x 6'4" High
Feed Table: 17'7" L x 5'9" W x 5'7" High
Main: 8'9" L x 5'9" W x 9'6" High
Weight: Main: 44,000 Lbs. Approx.
Other Components: 20,100 Lbs. Approx.
Loaded on Truck.............Toledo, (Campbell St. Whse.) OH
**PHOTO & CATALOGUE INFO AVAILABLE
